SKU: FF58F-12S
Size: 5/8″ Body with 3/4″ SAE Thread
Benefits:
- Flush face valve design minimizes fluid loss and air inclusion
- Zinc-nickel plating provides superior corrosion resistance
- Hardened steel construction with hardened sleeves
- Allows for minimal pressure drops
- Locking sleeve helps prevent accidental disconnects
- Nipple seal resists blow-outs
- Interchangeable with other ISO 16028 standard couplings
Features:
- 5,076 PSI rating
- 39.63 GPM Max Flow Rate
- 20 GPM Nominal Flow Rate
- Buna-N Seals with Teflon backup ring can operate up to 250° F
- Female Face Diameter: 1.65” (42mm)
- Female Length: 2.87” (73mm)
- Hex: 1.42” (36mm)
Interchangeable with:
| Manufacturer | Female |
| SUMMIT | FF58F-12S |
| Parker FE Series | FEM-621-12FO |
| Safeway FFE49 Series | N/A |
| Faster FFH Series | FFH10 34SAE F |
| Snap Tite 74 Series | 74C10-12EM |
| Stucchi FIRG Series | 800804010 |
| Dixon HT Series | 5HTOF6 |
| DNP PLT4 Series | FF-HPG-10-12C-SAE |
Kit Includes:
- 1 Female Coupler
| Weight | 1.18 lbs |
|---|---|
| Style | Flat Face |
| Body Size | 5/8" |
| Thread Type | |
| Thread Size | 3/4" |
| Body Material | Hardened Steel |
| Locking Type | Ball |
