1/2″ Flat Face Hydraulic Quick Connect Coupler Set, 3/8″ NPT Thread
SKU: FF12-06N-SET
Body Size: 1/2″ Body
Thread Size: 3/8″ NPT Thread
This coupler set uses a flat face design for spill resistance, much improved over its Agricultural or Pioneer counterpart. The design also minimizes pressure drops. With a robust steel design, the couplers easily can push-to-connect.
The flat face quick coupler features a hardy 5,076 PSI rating and has a maximum GPM flow rating of 23.78.
Features:
- Universal coupler and plug set
- Flush face valve design minimizes fluid loss
- Allows for minimal pressure drops
- Easy single-handed push-connect design
- Hardened steel construction with hardened sleeves
- Corrosion-resistant trivalent zinc plating
- Locking sleeve to prevent accidental disconnection
- Nipple seal resists blow-outs
- Seals are rated for operating temperature up to 250˚F
- 5,076 PSI rating
- 23.78 GPM Max Flow Rate
- Interchangeable with other ISO 16028 standard couplings
Looking for a different hydraulic quick disconnect coupler? Look at our selection of 1/2″ body Flat Face couplers here! If you do not need the full assembly, you can also find the male coupler and female coupler. All variants are available here through Summit Hydraulics.
| Weight | 2 lbs |
|---|---|
| Dimensions | 8 × 5 × 4 in |
| ISO Standard | |
| Style | Flat Face |
| Body Size | 1/2" |
| Thread Type | |
| Thread Size | 3/8" |
| Body Material | Hardened Steel |
| Locking Type | Ball |
| Coupling |
