Flat Face Hydraulic Quick Connect Coupler Set, 5/8 ORFS Bulkhead Mount
FF12-10ORFS-SET
KV11305 Female Side
Flat Face Hydraulic Quick Connect Coupler Set, 5/8 ORFS Bulkhead Mount - Image 4
KV11305 Close up
AT312876
KV11305
AT312876 closeup
AT312876 Male Side
Flat Face Hydraulic Quick Connect Coupler Set, 5/8 ORFS Bulkhead Mount
FF12-10ORFS-SET
KV11305 Female Side
KV11305 Close up
AT312876
KV11305
AT312876 closeup
AT312876 Male Side

Flat Face Hydraulic Quick Connect Coupler Set, 5/8 ORFS Bulkhead Mount

$64.95

Free Shipping on orders over $75

Free Shipping

Flat Face Hydraulic Quick Connect Coupler Set, 5/8 ORFS Bulkhead Mount

In stock

Quantity Per Item Price
2-3 $59.75
4-9 $58.46
10+ $55.21
SKU: FF12-10ORFS-SET Categories: , , Tags: ,

SKU: FF12-10ORFS-SET

  • Standard Skid Steer quick coupler (1/2” Body) interchangeable with ISO 16028 Flat Face Couplers
  • 5/8 ORFS Bulkhead adapter which allows direct mounting on machine
  • Used on various models of skid steers including CAT 216B, 226B, 232B, 236B, 242B, 246B, John Deere 217, 220
  • Heavy Duty Design with 5076 PSI Rating
  • Max Flow Rate: 23 GPM
  • Locking sleeve helps prevent accidental disconnects

Compatible With:

  • CAT: 216B, 226B, 232B, 236B, 242B, 246B, 248B, 252B, 262B, 268B
  • John Deere: 217, 220, 240, 250, 313, 315, 317, 318, 319, 320, 323, CT315, CT322

Replaces:

  • Parker FEM Series
  • Female: FEM-501-10BMS
  • Male: FEM-502-10BMS

Weight 3 lbs
Dimensions 8 × 5 × 4 in
Style

Flat Face
Body Size

1/2"
Thread Type

Thread Size

5/8"
Body Material

Hardened Steel
Locking Type

Ball
