SKU: FF58-12N-SET
Size: 5/8″ Body with 3/4″ NPT Thread
Features:
- Heavy Duty Design with 5076 PSI Rating
- Max Flow Rate: 39 GPM
- Locking sleeve helps prevent accidental disconnects
- Compact profile with high flow performance
- Harden steel construction with anti-corrosive plating
- Sleeves are hardened to resist deformation and maximize life of the coupler
- Valve design that allows for a minimal pressure drops and one hand operation
- Seals are rated for operating temperatures up to 250°F
Interchangeable with:
| Manufacturer | Male | Female |
| SUMMIT | FF58M-12N | FF58F-12N |
| Parker FE Series | FEM-622-12FP | FEM-621-12FP |
| Safeway FFE49 Series | N/A | N/A |
| Faster FFH Series | FFH10 34NPT M | FFH10 34NPT F |
| Snap Tite 74 Series | 74N10-12F | 74C10-12F |
| Stucchi FIRG Series | 800801011 | 800801010 |
| Dixon HT Series | HT5F6 | 5HTF6 |
| DNP PLT4 Series | FF-HPG-10-12N-NPT | FF-HPG-10-12C-NPT |
| Weight | 3 lbs |
|---|---|
| Dimensions | 5 × 4 × 4 in |
| ISO Standard | |
| Style | Flat Face |
| ISO Body Size | |
| Body Size | 5/8" |
| Thread Type | |
| Thread Size | 3/4" |
| Body Material | Hardened Steel |
| Locking Type | Ball |
| Coupling |
