SKU: HM4-08-H20
PRODUCT FEATURES
- Universal 4 circuit hydraulic multiplier
- Can operate with both double or single-acting cylinders
- Use with open, closed or FPC Hydraulic systems.
- Anodized body for durability and corrosion protection
- Heavy-duty chemical-proof and weather-resistant 12V DC solenoid valves (24V coils can be ordered)
- Up to 3000 PSI
PRODUCT DESCRIPTION
Hydraulic Multiplier that allows you to turn 1 hydraulic circuit into 4 circuits.
KIT CONTAINS
- Manifold block with 12V solenoid valves
- 20′ Wiring Harness
- 1-year manufacturer warranty
- 60-day returns policy
- Proudly made in the USA
| Weight | 20 lbs |
|---|---|
| Dimensions | 13 × 13 × 9 in |
| Actuation | 12V DC |
| Flow Rating | 20 GPM |
| Switch Type | Maintained |
| Number of Circuits | 4 |
