SKU: CV06N
Features:
- Check Valve – Allows flow in one direction
- Carbon Steel Body
- Opening/Cracking Pressure: 7.25 PSI
- Port Size: #6 SAE
- Max Flow: 8 GPM
- Max Pressure: 5000 PSI
- Operating Temp Range: -20 to 210 F
- Hex Diameter: 0.945” (24mm)
- Length: 2.28” (58mm)
| Weight | 1 lbs |
|---|---|
| Dimensions | 4 × 2 × 2 in |
| Flow Rating | 8 GPM |
| Thread / Port Size | |
| Maximum Pressure | 5,000 PSI |
| Valve Type | In-Line |
