SKU: DV50-08S-24V
Benefits:
- This solenoid operated valve allows you to easily add another hydraulic circuit to your equipment.
- Works with Double or Single Acting Cylinders
- Can be used on Open, Closed or FPC hydraulic systems
- Stackable valves can be combined to add up to 3 additional functions
- #8 SAE O-Ring ports ensure solid seal and prevent blockages
Features:
- 24v DC
- DIN 43650 Connector
- 6 Ports with #8 SAE (3/4”-16) Thread
- Max Operating Pressure: 3625 PSI
- Flow Rating: 13 GPM
- Made in Europe
| Weight | 10 lbs |
|---|---|
| Dimensions | 10 × 8 × 6 in |
| Actuation | Solenoid |
| Flow Rating | 13 GPM |
| Maximum Flow | 13 GPM |
| Maximum Pressure | 3,625 PSI |
| Thread / Port Size | |
| Connection Type |
3 reviews for Hydraulic Solenoid Selector/Diverter Valve, 13 GPM, 24v DC
Add a review
Larry –
Use it on 1025r for grapple fork.
Peter –
Should be put in service today but I expect no problems. Adding the fourth function to my front-end loader. It will be rotating the grapple head as well as opening & closing the grapple hooks. Part arrived immediately and has the best price you can imagine.
Donnie –
The valve worked very well as a duel section with a single control. I put it on a mini trackhoe for thumb control
