SKU: AG12F-08S
This series of couplers are the most common quick connect couplers used in the agriculture, construction and logging industries. They are interchangeable with all 1/2″ body ISO 5675 series / Pioneer style couplers including ball seat valve, poppet seal, and 1/2″ Body ISO 7241-A couplers.
Body Size: 1/2″ Body
Thread Size: #8 SAE (3/4″-16 ORB) Thread, Poppet Valve
This 1/2″ female coupler connects to its male equivalent. We also carry a complete set, including a single male and single female coupler.
Features:
- Nominal Flow Rate: 12 GPM
- Max Flow Rate: 24 GPM
- 3600 PSI Rating
- Hardened Steel Plugs
- 23,000 PSI Burst Rating (Coupled)
Interchangeable with:
| Manufacturer | Female |
| SUMMIT | AG12F-08S |
| Parker 4000 Series | 4050-15P |
| Safeway S20 Series | S25-15P |
| Faster NV/NS Series | NV 12-12SAE F |
| Dixon AG Series | 4AGOF4-PV |
What’s Included:
- Female Coupler
| Weight | 0.59 lbs |
|---|---|
| Dimensions | 4 × 3 × 2 in |
| ISO Standard | |
| Style | Agricultural |
| ISO Body Size | |
| Body Size | 1/2" |
| Thread Type | |
| Thread Size | #8 |
| Body Material | Hardened Steel |
| Locking Type | Sleeve |
| Coupling |
